FEATURES:
* Stainless steel, Hermetically welded, oil proof, waterproof and anti-corrosion.
* S beam type, tension or compression loading possible, easy installation.
* High accuracy and low profile.
* Suitable for measuring tension or compression loading as electronic
crane/hopper scales and other electronic weighing devices.
SPECIFICATIONS:
Capacity: 0.5/ 1/ 2/ 3/4/ 5/ 6/ 7.5 T;
Accuracy: C2; C3;
Max.number of verification intervals ( Nmax):2000; 3000;
Min. Load cell verification interval (Vmin):Emax/5000;Emax/10000;
Combine error( %FS):<± 0.030; <± 0.020;
Creep( %FS/30Min.): ≤±0.024; <± 0.016;
Temp.effect on sensitivity (%FS/10℃）: ≤±0.017; ≤±0.011;
Temp. Effect on zero (%FS/10℃）: ≤±0.023; ≤±0.015;
Output sensitivity (mV/V): 2.0 ±0.004;
Input resistance (Ohm): 350 ±3.5;
Output resistance (Ohm): 351 ±2.0;
Insulation resistance (M Ohm): > 5000 (VDC）
Zero balance ( %FS): 1.5;
Compensated temperature (℃）: -10 ~ 40;
Operating temperature (℃）: -35 ~65;
Excitation, recommended (V):5~12 (DC）;
Excitation, Max. (V): 18(DC）
Safe overload (%FS): 150;
Ultimate overload (%FS): 300.
