SPECIFICATIONS:

Capacity (t): 0.5/ 1/2/ 5/ 10/ 20;

Accuracy: G1; C1; C2;

Max.number of verification intervals ( Nmax):1000; 1000; 2000;

Min. Load cell verification interval (Vmin): Emax/2000; Emax/3000; Emax/5000;

Combine error( %FS): <0.050; <0.050; <0.030;

Creep( %FS/30Min.): < 0.050; < 0.038;< 0.024;

Temp.effect on sensitivity (%FS/10℃）:< 0.050; <0.028;< 0.017;

Temp. Effect on zero (%FS/10℃）: <0.050;< 0.047; < 0.023;

Output sensitivity (mV/V): 2.0 ±0.002;

Input resistance (Ohm):350 ±3;

Output resistance (Ohm): 351 ±2;

Insulation resistance (M Ohm): >5000(50VDC）;

Zero balance ( %FS): 1.0;

Compensated temperature ( ℃）: -10 ~ 40;

Operating temperature (℃）: -35 ~ 65;

Excitation, recommended (V): 5 ~12 (DC）;

Excitation, Max. (V): 18 (DC）;

Safe overload (%FS):150;

Ultimate overload (%FS): 300.
