SPECIFICATIONS:

Capacity (t): 15/20/30/50; 5/10; 1/2/3;

Accuracy: C1; C2; C3;

Max.number of verification intervals ( Nmax):1000; 2000; 3000;

Min. Load cell verification interval (Vmin): Emax/3000; Emax/5000; Emax/7500;

Combine error( %FS): <0.050; <0.030; <0.020;

Creep( %FS/30Min.): < 0.038; < 0.023;< 0.016;

Temp.effect on sensitivity (%FS/10℃）:< 0.028; <0.017;< 0.011;

Temp. Effect on zero (%FS/10℃）: <0.047;< 0.029; < 0.019;

Output sensitivity (mV/V): 2.0 ±0.01;

Input resistance (Ohm): 770 ±30;

Output resistance (Ohm): 770 + -52;

Insulation resistance (M Ohm): >5000(50VDC）;

Zero balance ( %FS): 1.5;

Compensated temperature ( ℃）: -10 ~ 40;

Operating temperature (℃）: -35 ~ 65;

Excitation, recommended (V): 5 ~12 (DC）;

Excitation, Max. (V): 18 (DC）;

Safe overload (%FS):150;

Ultimate overload (%FS): 300.
