FEATURES:
* Stainless steel, welded with bellow, potted by adhesive inside,
oil proof, waterproof and anti-corrosion.
* Single point with bellow, easy installation.
* High accuracy and low profile.
* Suitable for electronic crane/hopper/mechanical conversion scales
and other electronic weighing devices.
Capacity: 5/ 10/ 20/ 30/ 50/ 100/ 200/ 250/ 300/ 350/ 500KG;
Accuracy: C2; OIML R60 C3;
Max.number of verification intervals ( Nmax): 2000; 3000;
Min. Load cell verification interval (Vmin): Emax/5000; Emax/10000;
Combine error( %FS): ≤±0.030; ≤±0.020;
Creep( %FS/30Min.): ≤±0.024; ≤±0.016;
Temp.effect on sensitivity (%FS/10℃）: ≤±0.017; ≤±0.011;
Temp. Effect on zero (%FS/10℃）: ≤±0.023; ≤±0.015;
Output sensitivity (mV/V): 2.0 ±0.02;
Input resistance (Ohm): 460 ±50 ;
Output resistance (Ohm): 351 ±2;
Insulation resistance (M Ohm): 5000(50VDC）;
Zero balance ( %FS): 1.0;
Compensated temperature (℃）: -10 ~40;
Operating temperature (℃）: -35~65;
Excitation, recommended (V): 5~12(DC）
Excitation, Max. (V): 18 (DC）
Safe overload (%FS): 150;
Ultimate overload (%FS) : 300.
