SPECIFICATIONS:

1) Capacity (kg):  0.2, 0.3, 0.6, 1, 2, 3.

2) Combined error (%FS): 0.02

3) Rated output (mV/V): 0.9 ± 0.1

4) Non-linearity (%FS): 0.02

5) Non-repeatability (% FS): 0.01

6) Hysteresis (%FS): 0.02

7) Creep (%FS/30min): 0.02

8) Temperature effect on spen. (%FS/10o℃）: 0.03

9) Temperature effect on zero (%FS/10o℃）: 0.03

10) Zero balance (%FS): 4.0

11) Input resistance (Ω): 394 ± 6

12) Output resistance (Ω): 350 ± 3

13) Insulation resistance (mΩ) (50V DC）: ≥5,000

14) Recommended excitation (V) (DC）: 9 - 12

15) Excitation permission (DC）: 6 – 18V

16) Compensated temperature (℃）: -10 ~ +40

17) Operating temperature (o℃）: -20 ~ +65

18) Safe overload (%FS): 150

19) Ultimate overload (%FS): 300

20) Protection class: 1P65
