SPECIFICATIONS:

Capacity: 50/ 75/ 100/ 150/ 200/ 250/ 300/ 500/ 635/ 1000T KG;

Accuracy: C3D; OIML R60 C3; C3G;

Max.number of verification intervals ( Nmax): 2500; 3000; 4000;

Min. Load cell verification interval (Vmin): Emax/5000; Emax/7000; Emax/11000;

Combine error( %FS): ≤±0.030; ≤±0.020; ≤±0.015;

Creep( %FS/30Min.):  ≤±0.020; ≤±0.0167; ≤±0.0125;

Temp.effect on sensitivity (%FS/10℃）:≤±0.021; ≤±0.0175; ≤±0.0131;

Temp. Effect on zero (%FS/10℃）: ≤±0.028; ≤±0.020; ≤±0.0127;

Output sensitivity (mV/V): 2.0 ±0.2;

Input resistance (Ohm): 409 ±6 ;

Output resistance (Ohm): 350 ±3  ;

Insulation resistance (M Ohm): >5000(50VDC）;

Zero balance ( %FS): 2;

Compensated temperature (℃） : -10 ~ 40;

Operating temperature (℃） : -35 ~65;

Excitation, recommended (V): 5~12(DC）;

Excitation, Max. (V): 18(DC）;

Safe overload (%FS): 150;

Ultimate overload (%FS): 300

Corner correction:  0.02%load value/100mm
