SPECIFICATIONS:

Capacity:  75/ 100/ 150/ 200/ 300/ 400/ 500 KG;

Accuracy: C2; C3;

Max.number of verification intervals ( Nmax): 2000; 3000;

Min. Load cell verification interval (Vmin): Emax/5000; Emax/10000;

Combine error( %FS): ≤±0.030; ≤±0.020;

Creep( %FS/30Min.):  ≤±0.024; ≤±0.016;

Temp.effect on sensitivity (%FS/10℃）:≤±0.017; ≤±0.011;

Temp. Effect on zero (%FS/10℃）: ≤±0.023; ≤±0.015;

Output sensitivity (mV/V): 2.0 ±0.2 / 2.0 ±0.002;

Input resistance (Ohm): 350 ±3.5 ;

Output resistance (Ohm): 351 ±2.0  ;

Insulation resistance (M Ohm): >5000(50VDC）;

Zero balance ( %FS): 1.5;

Compensated temperature (℃） : -10 ~ 40;

Operating temperature (℃） : -35 ~65;

Excitation, recommended (V): 5~12(DC）;

Excitation, Max. (V): 18(DC）;

Safe overload (%FS): 150;

Ultimate overload (%FS): 300

Corner correction:  0.02%load value/100mm
