SPECIFICATIONS:

Capacity: 0.3/ 0.4/ 0.5/ 0.6/ 1/ 3 KG;

Accuracy:  C3D;

Max.number of verification intervals ( Nmax): 2500;

Min. Load cell verification interval (Vmin): Emax/5000;

Combine error( %FS): ≤±0.030;

Creep( %FS/30Min.):  ≤±0.020;

Temp.effect on sensitivity (%FS/10℃）:≤±0.021;

Temp. Effect on zero (%FS/10℃）: ≤±0.028;

Output sensitivity (mV/V):  1.0 ±0.1;

Input resistance (Ohm): 394 ±6 ;

Output resistance (Ohm): 350 ±3  ;

Insulation resistance (M Ohm): >5000(50VDC）;

Zero balance ( %FS): 2;

Compensated temperature (℃） : -10 ~ 40;

Operating temperature (℃） : -35 ~65;

Excitation, recommended (V): 5~12(DC）;

Excitation, Max. (V): 18(DC）;

Safe overload (%FS): 150;

Ultimate overload (%FS): 300

Corner correction:  0.02%load value/100mm
