SPECIFICATIONS:

  Capacity:                     1 ~ 10, 20, 50, 100Kg

  Rated output:                 1.0 mV ± 0.10 mV

  Non-linearity:                 ≤ 0.2% FS

  Hysterisis:                    ≤ 0.2% FS

  Repeatability:                 ≤ 0.1% FS

  Creep:                       ≤ 0.05% FS/30 Min.

  Zero balance                  ≤ ±1% FS

  Temperature effect on span:     ± 0.1%FS/10℃

  Temperature effect on zero:     ± 0.1%FS/10℃

  Input resistance:               350  ± 5 Ohm

  Output resistance:              350  ± 5 Ohm

  Insulation resistance:           > 2000M Ohm

  Excitation voltage:             10 V dc

  Operating temperature:         -20 ~ + 60℃

  Safe overload:                     150%FS
