SPECIFICATIONS:

Capacity:  20 kg

Combine Error: 0.1;

Output sensitivity (mV/V): 2.5 ±0.4 mV/V;

Non-linearity: ±0.05%FS;

Repeatability: ±0.05%FS;

Hysteresis: ±0.05%FS;

Creep( %FS/3Min.):  ±0.1;

Temp.effect on span (%FS/10℃）: ±0.3;

Temp. Effect on zero (%FS/10℃）: ±0.3;

Input resistance (Ohm): 350 ±50;

Output resistance (Ohm): 350 ±50;

Insulation resistance (M Ohm): >2000(50VDC）;

Zero balance ( %FS): ±1.0 mV/V;

Operating temperature (℃）: -10 ~ 40;

Excitation, Max. (V): 10 (DC）;

Safe overload (%FS): 150;
