SPECIFICATIONS:

Capacity: 2 T;

Accuracy: C1; C2; C3;

Max.number of verification intervals ( Nmax): 1000/ 2000/ 3000;

Min. Load cell verification interval (Vmin): Emax/3000; Emax/5000; Emax/10000;

Combine error( %FS): ≤±0.050; ≤±0.030; ≤±0.020;

Creep( %FS/30Min.):≤±0.038; ≤±0.024; ≤±0.016;

Temp.effect on sensitivity (%FS/10℃）:   ≤±0.028; ≤±0.017; ≤±0.011;

Temp. Effect on zero (%FS/10℃）:  ≤±0.047; ≤±0.023; ≤±0.015;

Output sensitivity (mV/V): 1.2 ±0.004;

Input resistance (Ohm): 700 ±7 ;

Output resistance (Ohm):  703 ±4;

Insulation resistance (M Ohm):  5000(50VDC）;

Zero balance ( %FS):  2.5;

Compensated temperature (℃）: -10 ~40;

Operating temperature (℃）: -35~65;

Excitation, recommended (V): 5~12(DC）;

Excitation, Max. (V):  18(DC）

Safe overload (%FS): 150;

Ultimate overload (%FS) : 300.
