SPECIFICATIONS:

Capacity: 0.5/ 1/1.5/ 2/ 2.5/ 3/ 5/ 10 T;

Accuracy: C2; OIML R60 C3; C4;

Max.number of verification intervals ( Nmax): 2000; 3000; 4000;

Min. Load cell verification interval (Vmin): Emax/5000; Emax/10000; emax/14000;

Combine error( %FS): ≤±0.030;  < ±0.020; ≤±0.018;

Creep( %FS/30Min.): < ±0.024; < ±0.016; ≤±0.012;

Temp.effect on sensitivity (%FS/10℃）: < ±0.017; < ±0.011; ≤±0.009;

Temp. Effect on zero (%FS/10℃）: < ±0.023; < ±0.015; < ±0.010;

Output sensitivity (mV/V): 2.0 ±0.002;

Input resistance (Ohm): 350 ±3.5;

Output resistance (Ohm): 351 ±3.5;

Insulation resistance (M Ohm): > 5000(VDC）;

Zero balance ( %FS): 1.0;

Compensated temperature (℃）: -10 ~40;

Operating temperature (℃）: -35 ~65;

Excitation, recommended (V): 5 ~12(DC）;

Excitation, Max. (V): 18(DC）;

Safe overload (%FS): 150;

Ultimate overload (%FS): 300.
