Capacity: 0.5/ 1/2/2.5/ 3/ 5/ 10/ 15/ 20/ 25/ 30/ 50 T;

Accuracy: C2; OIML R60 C3;

Max.number of verification intervals ( Nmax): 2000; 3000;

Min. Load cell verification interval (Vmin): Emax/5000; Emax/10000;

Combine error( %FS): ≤±0.030;  < ±0.020;

Creep( %FS/30Min.): < ±0.024; < ±0.016;

Temp.effect on sensitivity (%FS/10℃）: < ±0.017; < ±0.011;

Temp. Effect on zero (%FS/10℃）: < ±0.023; < ±0.015;

Output sensitivity (mV/V): 2.0 ±0.002;

Input resistance (Ohm): 350 ±3.5;

Output resistance (Ohm): 351 ±2;

Insulation resistance (M Ohm): > 5000(VDC）;

Zero balance ( %FS): 1.0;

Compensated temperature (℃）: -10  ~ 40;

Operating temperature (℃）: -35 ~65;

Excitation, recommended (V):5~12 (DC）;

Excitation, Max. (V): 18(DC）

Safe overload (%FS): 150;

Ultimate overload (%FS): 300.
