FEATURES:
* Aluminum material, sealed silicon adhesive, surface spraying plastic with good
resistance and anti-corrosion.
* S beam type, easy installation.
* High accuracy and high reliability.
* Suitable for textile machinery measuring and other electronic measuring devices.
SPECIFICATIONS:
Capacity: 200/500 kg;
Accuracy: C2;
Max.number of verification intervals ( Nmax):2000;
Min. Load cell verification interval (Vmin):Emax/5000;
Combine error( %FS):<± 0.030;
Creep( %FS/30Min.): ≤±0.024;
Temp.effect on sensitivity (%FS/10℃）: ≤±0.017;
Temp. Effect on zero (%FS/10℃）: ≤±0.023;
Output sensitivity (mV/V): 2.3 ±0.04;
Input resistance (Ohm): 410 ±30;
Output resistance (Ohm): 351 ±2.;
Insulation resistance (M Ohm): > 5000 (VDC）
Zero balance ( %FS): 2;
Compensated temperature (℃）: -10 ~ 40;
Operating temperature (℃）: -35 ~65;
Excitation, recommended (V):5~12 (DC）;
Excitation, Max. (V): 18(DC）
Safe overload (%FS): 150;
Ultimate overload (%FS): 300.
